175KHZ Long Range Ultrasonic Sensor High Sound Pressure Liquid Level For Locating

Product Categories

Chengdu Haoli Electronic Technology Co.,Ltd.

Contact Now

Name: 175KHZ Long Range Ultrasonic Sensor High Sound Pressure Liquid Level For Locating
Brand: HAOLI
Price: 1 USD

Brand Name : HAOLI

Model Number : HL-175-30

Certification : CE，ISO9001，ROHS

Place of Origin : ChengDu

MOQ : 500

Price : Negotiation

Payment Terms : TT

Supply Ability : 1000pcs/10days

Delivery Time : 10work days

Frequency : 175±5KHZ

Capacicent : 400±20%

Dalay Time : ≤0.5ms

Sensitivity : -60min

Directivity : 7±1°

Operating Temperature : -30℃—+80℃

Contact Now

175KHZ Long Distance Ultrasonic Sensor Dual Use

Product Description

Application:

Center frequency	175.0±5.0KHz
Bandwidth	10Khz
Echo Sensitivity	-60dB min
Min.Parallel Resistance	250Ω±30%
Capacitance	400±20%pF
Typical Sensing Range	0.1~2m
Directivity deg	7°±2°(-6dB)
Max.Input Voltage	500Vp-p
Protection Class	IP65
Min.Parallel Resistance	250±50Ω
Mechanical quality factor(Qm)	min.40
Operating Temperature	-20-+80℃
Storage Temperature	-35-+85℃
Housing Material	Copper

175KHZ Long Range Ultrasonic Sensor High Sound Pressure Liquid Level For Locating

Product Tags:

distance measuring transducer sensor
